WIRELESS NR ROUTER 5G LTE TENDA 5G03 QUAD-CORE WI-FI6 1P GIGA LAN/WAN 1P GIGA 8 ANT.INT+2 EST.

Descrizione

WIRELESS NR ROUTER 5G LTE TENDA 5G03 QUAD-CORE WI-FI6 1P GIGA LAN/WAN 1P GIGA 8 ANT.INT+2 EST.

Hardware Specifications
Processor: Quad-Core, frequenza 2 GHz, processo produttivo a 7nm
Cellular Technologies: 5G/4G/3G Multi-Mode, 5G NR SA/NSA, 4G FDD/TDD LTE, 3G WCDMA
5G NR 3GPP: Release 15
5G NR Peak Download Speed: 4.67 Gbps
5G NR Peak Upload Speed: 1.25 Gbps
NR Frequency Band:
– 5G NR (Bande n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78)
– FDD-LTE (Bande 1, 3, 5, 7, 8, 20, 28, 32)
– TD-LTE (Bande 38, 40, 41, 42, 43)
– WCDMA (850, 900, 2100 MHz)
5G NR Download MIMO: SISO,2*2,4*4
5G NR Upload MIMO: SISO,2*2
5G NR Download Modulation: QPSK, 16QAM,64QAM,256QAM
5G NR Upload Modulation: QPSK, 16QAM,64QAM,256QAM
Wireless Connectivity: Wi-Fi 6 (802.11ax) with 2×2 MIMO
Wi-Fi speed:
– 574Mbps a 2.4 GHz
– 1201Mbps a 5 GHz
Wi-Fi standards: 802.11b/g/n,802.11ac,802.11AX
Wi-Fi frequency: 2.4GHz,5GHz
Wi-Fi transmit Power:
– 2.5GHz:fino a 20dBm
– 5GHz: fino a 23dBm
Ethernet Ports:
– 1 × 10/100/1000 Mbps LAN/WAN
– 1 × 10/100/1000 Mbps LAN
SIM Card:
– Dual SIM (nano-SIM and eSIM) 1 ×nano-SIM(4FF)
– Card Slot 1× eSIM
Button:
– 1× accensione/spegnimento
– 1× reset
– 1×MESH/WPS
Antennas and Ports:
– 8 × antenne interne 5G/4G
– 2 × antenne Wi-Fi interne
– 2 porte TS-9 per antenne

Software Specifications
WAN Type: 4G/5G o cablato
5G/4G Features:
– Auto-APN
– 5G SA/NSA dual mode
– Auto dial-up
– 5G Location optimization
– 5G/4G E-UTRAN New Radio–Dual Connectivity
– Roaming
– SMS(Send/Receive/Delete)
– USSD
– Data limted
– PIN Management
Wi-Fi functions:
– Visualizzazione e oscuramento nome rete Wi-Fi
– Priorità 5GHz Wi-Fi
– Rete ospiti
– Programmazione Wi-Fi
– OFDMA
– MU-MIMO
Wi-Fi security: WPA2/WPA3,WPA/WPA2,WPA2-PSK,WPA-PSK,WEP
Software features:
– EasyMesh
– Parental control
– DHCP(DHCP Server and Client)
– Virtual Server(UPnP/DMZ/Port Forwarding)
– DDNS(DynDns, 88ip)
– VPN(PPTP Client/L2TP Client/PPTP Server/IPSEC)
– Firewall
– QOS
– Upgrade firmware from local or OTA

Certifications
Certifications:
– FCC Granted
– CE Granted
– ROHS Granted

Working Environment
Temperature:
– Temperature operative: 0℃~40℃
– Temperature di storage: -30ºC~70ºC
Humidity:
– Umidità operativa: 10% ~ 90% RH non condensata
– Umidità di storage: 5% ~ 90% RH non condensata

Package lists
Contents:
– 1 x Router 5G NR
– 1 x cavo Ethernet
– 1 x alimentatore
– 1 x guida utente
