SWITCH 5P LAN GIGABIT UBIQUITI USW-FLEX DI CUI 4P POE+

Descrizione

SWITCH 5P LAN GIGABIT UBIQUITI USW-FLEX DI CUI 4P POE+

Mechanical
Dimensions: 122.5 x 107.1 x 28.0 mm (4.82 x 4.22 x 1.10″)
Weight: 230 g (8.11 oz)

Hardware
Networking Interfaces: (5) 10/100/1000 Mbps RJ45 Ports
Management Interface: Ethernet In-Band
PoE Out (Ports 2-5): PoE+ (Pins 1, 2+; 3, 6-)
Max Power Consumption (Excluding PoE Output): 5W
Max PoE Wattage Per Port: 25W
Total PoE Power Budget:
– Powered by PoE: 8W
– Powered by PoE+: 20W
– Powered by PoE++: 46W
– Powered by PoE Adapter (Enabled in Controller): 46W
Voltage Range:
– PoE: 44 – 57V
– PoE+/PoE++: 50 – 57V
LEDs:
– System: Status
– RJ45 Data Ports: PoE; Link/Speed/Activity
ESD/EMP Protection: ± 16kV Air, ± 16kV Contact
Operating Temperature:
– 46W PoE Output: -40 to 55° C (-40 to 131° F)
– 25W PoE Output: -40 to 65° C (-40 to 149° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: CE, FCC, IC

Power Method (Port 1)
PoE Type: Recommended PoE Source
PoE/PoE+ (Pins 1, 2+; 3, 6-): USW-24-PoE (sold separately)
PoE++ (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-): USW-Pro-24-PoE (sold separately)
50V/60W PoE Adapter: PoE Injector, POE-50-60W-WH or POE-50-60W (sold separately)
